| Cutting Diameter (DC) | 3 mm | Usable Length (LU) | 10 mm |
| Connection Diameter Machine Side (DCONMS) | 3 mm | Corner Radius (RE) | 1-1/2″ |
| Depth of Cut Maximum (APMX) | 10 mm | Tool Type | Single-End |
| Overall Length (OAL) | 39 mm | Length Group | Standard |
| Cutting Edge Material | Carbide | End Shape | Ball Nose |
| Coating | Uncoated | Style | Ball |
| Flute Count (NOF) | 4 | Measurement Type | Metric |
| Shank Type | Round | Series/List # | 404BN |
Product Features
| Remarks | •Micrograin Carbide End Mill •Regular Length •Ball End •4 Flute | Country of Origin | Japan |
Shipping Info
Package Length
2.65000
Package Width
.45000
Package Height
.45000
Package Weight
0.015
